No
|
Equipments
|
Model
|
Quantity
|
Specification
|
|
1
|
Brine metrology mixer
|
YSH100
|
1set
|
Power 0.75 kw, the capacity of 100 L/units
Stailess steel |
|
2
|
Supply metering device
|
YSJ10
|
1 set
|
Volume of 110 liters with liquid level display, round of tank, stainless steel, the pump is 0.75 kw,
|
|
3
|
Double speed dough mixer
|
HMJ200
|
1set
|
Power: 9/11kw, 200kg/po, Manually open door, contact part is stainless steel
|
|
4
|
Disc curing machine
|
PS200
|
1set
|
Power:4kw,Tray:φ2000mm*410,contact part is stainless steel
|
|
5
|
Single continuous rolling machine
|
MT7-50
|
1set
|
gracked glaze width:350mm, Power:5.5kw+5.5kw, 7 pair steel roller, frequency control, roller diameter φ300*1, φ240*2, φ180*4
|
|
6
|
Single-layer steamed noodles machine
|
CZM50
|
1set
|
24 meters, water seal,
Main drive 1.5 kw (frequency control of motor speed), fan, 0.37 kw×2set, stainless steel |
|
7
|
Cutting and folding machine
|
QF50
|
1set
|
Main drive 1.5 kw (frequency control of motor speed), air knife:0.9 kw,
With spray device. |
|
8
|
Fried dryer
|
YZ50
|
1set
|
Main drive 2.2 kw (frequency control of motor speed), lift power:2.2 kw, Circulating pump:7.5kw, gear pump:2.2 kw，air knife:0.9 kw, 40m2 spiral heat exchanger 1 set, 2m3 oil tank 1set
|
|
9
|
Air cooling device
|
FL50
|
1set
|
(frequency control of motor speed)
Fan:0.37 kw*10set, exhaust fan:3kw |
|
10
|
Conveyor
|
SS120
|
2set
|
Main drive 0.37*2KW
(frequency control of motor speed), stainless steel |
|
11
|
Products conveyor
|
CS120
|
2set
|
Main drive 0.37 kw, contact parts,stainless steel
|
|
12
|
Electric control cabinet
|
BPT-1
|
Whole set
|
The main process adopts frequency control of motor speed,
PLC program control |
|
|
Total
|
|
|
Total equipments power ~ 55 kw
|
